COMPATIBILITY TABLE
T-510 | Supported Screw Feeder |
Model Number | |
T-510S | NSB/ NSR/ NSBI/ NSRI/ NSRI-B |
T-510J | NJ/ NJR |
Stock capacity based on the diameter and length of the screw for 400cc: M2.3×5, approx. 10,000; M3.0x6, approx. 2,800
SPECIFICATIONS:
Model Name | T-510 |
Exterior Dimensions | 130(W)x171(D)x245(H) With auxiliary stocker installed 295 (H) |
Volume (including the rail) | Approx. 3.1kgf |
Power | AC100V – 240V DC15V 1A AC adapter |
Drive Motor | DC brush motor |
External Signal line (remaining quantity sensor) | o |
Safety Function | – |
Supported screw diameter | M1.0 – M6.0 |
Supported screw under-head length | Up to 25mm in length |
Screw capacity | Main Component: Approx. 400cc Auxiliary Stocker: Approx. 400cc |
Accessories and bundled items | Instruction Manual, Auxiliary Stocker, AC adapter, hex wrench, screw (M2.6×5), external signal line/ mounting plate |
